Percentage Routing & A/B Testing API

Intelligently split click traffic across landing page variants to maximize conversion rates.

4 min read•Official Edge Documentation

Overview & Architecture

Percentage routing (A/B Testing) directs a defined proportion of traffic to different page variations (e.g., 50% to Variant A, 50% to Variant B, or 70% / 15% / 15%).

Routing decisions execute directly on Cloudflare Edge servers during the network handshake, with zero client scripts or visible layout flicker.

Key Principles

Core architectural pillars ensuring high performance, isolation, and security.

01Weighted Edge Distribution

Define custom percentage weights (sum = 100%) between the primary URL and A/B variations.

02Zero Flicker

Routing happens before HTML page load, eliminating visual shifts for visitors.

03Comparative Conversion Analytics

Analyze click volumes, conversion rates, and revenue generated by each variant in your dashboard.

SDK Integration

Implementation & SDK Examples

Ready-to-use TypeScript code snippets and configuration examples for your integrations.

1. Creating an A/B Test via SDK

Associate variations with their respective percentage weights:

create-ab-test.ts

typescript

12345678910111213141516171819
import { lshorter } from "@/lib/lshorter";

const abLink = await lshorter.links.create({
  url: "https://your-store.com/landing-a",
  slug: "promo-split",
  mainWeight: 50, // 50% to landing A
  abVariations: [
    {
      id: "var_b",
      targetUrl: "https://your-store.com/landing-b",
      weight: 50, // 50% to landing B
      name: "Variant B (Green Button)",
    },
  ],
  tags: ["ab-test", "marketing-q4"],
});

console.log("A/B Testing short link active:", abLink.shortUrl);
// Output: https://lsho.cc/promo-split

REST API Specification

API Endpoints & Reference

Direct HTTP request methods, parameters schema, authentication, and responses.

PATCH

Configure A/B Test Routing

Bearer <API_KEY>60 to 1,400 req/min (by plan)

https://lsho.cc/api/v1/links/:id/ab

Configures or updates percentage traffic split weights across multiple landing page variants.

Path Parameters

Parameter	Type	Required	Description	Example
id	string	Required	Short link slug or ID.	`promo-split`

Request Body Parameters

Parameter	Type	Required	Description	Example
mainWeight	number	Required	Percentage of traffic sent to the primary target URL (0 to 100).	`50`
abVariations	object[]	Required	Array of variant configurations.	`[{"id": "var_b", "targetUrl": "https://store.com/landing-b", "weight": 50, "name": "Variant B (Green Button)"}]`
abVariations[].id	string	Required	Unique variant key.	`var_b`
abVariations[].targetUrl	string (url)	Required	Destination URL for this variant.	`https://store.com/landing-b`
abVariations[].weight	number	Required	Percentage weight allocated to this variant.	`50`
abVariations[].name	string	Optional	Human-readable label for dashboard comparison.	`Variant B (Green Button)`

Request Examples

bash

1234567891011121314
curl -X PATCH "https://lsho.cc/api/v1/links/promo-split/ab" \
  -H "Authorization: Bearer $LSHORTER_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "mainWeight": 50,
    "abVariations": [
      {
        "id": "var_b",
        "targetUrl": "https://store.com/landing-b",
        "weight": 50,
        "name": "Variant B (Green Button)"
      }
    ]
  }'

Response Payload

200 OKA/B testing weights updated.

response-200.json

json

12345678910111213141516
{
  "id": "link_ab_991823",
  "slug": "promo-split",
  "shortUrl": "https://lsho.cc/promo-split",
  "mainWeight": 50,
  "abVariations": [
    {
      "id": "var_b",
      "targetUrl": "https://store.com/landing-b",
      "weight": 50,
      "name": "Variant B (Green Button)",
      "clicksCount": 0
    }
  ],
  "status": "active"
}

A/B Testing Link Structure

Payload confirming percentage routing weights:

response.json

json

1234567891011121314151617
{
  "id": "link_ab_991823",
  "slug": "promo-split",
  "shortUrl": "https://lsho.cc/promo-split",
  "targetUrl": "https://your-store.com/landing-a",
  "mainWeight": 50,
  "abVariations": [
    {
      "id": "var_b",
      "targetUrl": "https://your-store.com/landing-b",
      "weight": 50,
      "name": "Variant B (Green Button)",
      "clicksCount": 128
    }
  ],
  "status": "active"
}

Recommended Best Practices

Expert tips to maximize performance, resilience, and link security.

Recommendation 01

Ensure total weight sums to exactly 100% (mainWeight + sum of variation weights = 100).

Recommendation 02

Run tests until reaching statistically significant sample sizes (at least 500 to 1,000 clicks per variant).

Recommendation 03

Test only one major variable per experiment (e.g. headline vs hero image) to clearly identify causality.
